Standard Features:
- High Contrast 7" Silver Bright LCD for excellent sunlight viewability
- 14 range scales from 0.125 to 24 nm
- Low power consumption in Watchman mode - only 8 W
- Dual bandwidth IF amplifier: broad band for high fidelity in short ranges, narrow band for enhanced detection in long ranges
- Variable antenna speeds with range scales for optimum performance on all ranges
- Cursor position can be read in L/L (GPS Navigator is required)
- Waypoint Lollipop On-Screen to aid in Vessel Navigation (GPS Navigator is required)
- Programmable Navigation Data repeater feature
- Zoom in to a specific area
- Reverse video feature for effective use at night
- Guard Zone Alarm (US Patent No.5032842)
Power Requirements:
- 12 to 24 VDC, 38 W (max), 8 W (in Watchman mode)
- 115/230 VAC with optional rectifier PR-62
Shipping Information:
- 29 lbs, 1 Carton
- 13"x 21"x 28"
